Butane Gas Torch

Heavy-Duty Bayonet Butane Gas Torch | OEM & ODM Manufacturer

This bayonet-style butane gas torch is engineered for professional plumbing, HVAC repair, metal brazing, and high-intensity workshop heating. Utilizing a secure twist-and-lock bayonet connection, it mates firmly with standard disposable butane canisters to maintain a stable, leak-resistant seal under continuous operation. Built for industrial distributors and hardware brand owners, our manufacturing facility delivers consistent flame output, durable brass-aluminum internal valving, and reliable piezo electronic ignition.

First 12 3 4 Last

Product Type

Classification

Handheld Portable Gas Torch / Bayonet Connection Type.

Operation Mode

Manual trigger ignition with adjustable needle valve gas control.

Fuel Compatibility

Standard EN417 bayonet-type butane and butane-propane mix canisters.

Key Structure & Technical Specifications

01/

Ignition System: Integrated Piezo Electronic Igniter (rated for over 30,000 continuous strikes).

02/

Burner Tube Material: Stainless steel flame nozzle with high-temperature ceramic insulation core.

03/

Valve Assembly: Precision brass gas control valve and zinc alloy housing.

04/

Max Flame Temperature: Up to 1,300 degrees Celsius (2,372 degrees Fahrenheit).

05/

Gas Consumption Rate: Approx. 80g to 140g per hour depending on flame setting.

06/

Dimensions and Weight: Standard portable profile; net weight ranges from 150g to 220g (excluding canister).

Product Use

01.

Plumbing and HVAC

Soldering copper pipes, thawing frozen lines, and minor pipe fitting.

02.

Automotive Repair

Loosening rusted bolts, nuts, and heat-shrinking wire insulation.

03.

Metalworking and Jewelry

Low-temperature brazing, silver soldering, and artisanal craft shaping.

04.

Outdoor and Culinary

Rapid charcoal ignition, campsite fire starting, and surface food searing.

OEM & Customization Options

Private Labeling

Laser-etched brand logos on the stainless steel barrel or pad-printed housing.

Color Schemes

Custom injection-molded body colors matched to Pantone references for brand distinction.

Packaging Solutions

Custom clamshell blister packs, color display boxes, or bulk industrial carton packaging.

Accessory Bundles

Optional bundled kits including blow-molded carrying cases or matching butane fuel adapters.

Manufacturing & Quality Control Overview

Production Capacity

Automated assembly lines supported by precision CNC machining centers for valve components.

Material Testing

Incoming spectral analysis of brass and stainless steel raw materials to verify alloy composition.

Pressure Testing

100% online pneumatic pressure testing of valve assemblies to prevent gas leakage prior to final packaging.

Ignition Reliability Test

Automated spark testing on every unit to ensure consistent ignition success rates.

Compliance Standards

Manufactured under ISO 9001 quality management guidelines; compliant with relevant CE and EN417 safety parameters.

Packaging & Transportation

Export-grade moisture- and impact-resistant packaging is used. Each unit is individually packed in a color box and protected by reinforced corrugated cartons. EXW, FOB and DDP trade terms are available for negotiation. Standard products have a lead time of approximately 15 days, while customized products generally require around 25 days. Tracking information is provided after shipment to assist customers with delivery inspection.

productcate-1-1

FAQ

Q: What type of gas canisters are compatible with this bayonet torch?

A: The torch is designed to fit standard bayonet-connection butane and butane-propane aerosol canisters conforming to standard EN417 interface specifications.

Q: What is the minimum order quantity (MOQ) for OEM custom branding?

A: The standard MOQ for custom body colors and laser-etched branding is 1,000 units per order. Smaller trial batches for neutral packaging can be discussed upon request.

Q: How is gas leakage prevented at the connection point?

A: The bayonet connector incorporates a dual O-ring sealing mechanism and a spring-loaded locking collar that establishes a positive gas seal when twisted into position.

Q: Can the flame intensity and shape be adjusted?

A: Yes. The integrated brass needle valve allows precise adjustment from a fine precision needle flame to a high-output roaring swirl flame.

Q: What is the lead time for bulk production orders?

A: Standard production lead time ranges from 25 to 35 days following order confirmation and sample approval, depending on the scale and customization requirements.

Q: What quality control documents are provided prior to shipment?

A: We supply full inspection reports including raw material certificates, dimensional check sheets, 100% pressure-test logs, and pre-shipment inspection (PSI) summaries.

As one of the most professional bayonet spray gun manufacturers and suppliers in China, we're featured by quality products and good service. Please rest assured to buy durable bayonet spray gun at low price from our factory. We also accept customized orders.

Butane Gas Cartridge Blow Torch, bayonet spray gun, Hand Held Butane Blow Torch
